  • No 62 Gulf View Apartment Garage

No 62 Gulf View Apartment Garage

49.99
Gulf View 2.png
Gulf View 1.png
No. 62 Gulf View Garage Apartment_05.jpg
No. 62 Gulf View Garage Apartment_10.jpg

No 62 Gulf View Apartment Garage

49.99

Enter to win this plan on Labor Day (Enter here)

PROJECT DATA

DESIGN STANDARD(S): 2015 INTERNATIONAL RESIDENTIAL CODE,  ANSI METHOD USED TO CALCULATE SQUARE FOOTAGE.

SEISMIC DESIGN CATEGORY: D1

WIND DESIGN CATEGORY: C

FIRST FLOOR LOAD: SEE ENGINEERING

SECOND FLOOR LOAD: SEE ENGINEERING

ROOF LOAD: SEE ENGINEERING

SNOW LOAD: 25PSF

BUILDING SIZE: 28’ X 30’ (840 SF)

LIVING SPACE: 840 SF

GARAGE: 840 SF

PORCH (INCLUDING STAIRS): 640 SF

LEVELS: 2

OVERALL HEIGHT: 23’ - 11”

BEDROOMS: 1

BATHROOM: 1.75

FOUNDATION: DEEP FOOTING SLAB

HEATING: DUCTLESS MINI-SPLIT

WATER HEATING: TANK ELECTRIC

PRINT SIZE: ARCH D 24" X 36” (A1 594 X 841); BLACK & WHITE SHEETS
