  • #65 Mallard Sea Cottage

#65 Mallard Sea Cottage

99.00

#65 Mallard Sea Cottage

99.00

House Details

  • Design standard: 2018 International Residential Code (IRC)

  • Seismic design: D1

  • Wind design: Exposure B

  • 1st floor area: 40 PSF LIVE / 10 PSF DEAD

  • 2nd floor area: 30 PSF LIVE / 10 PSF DEAD

  • Roof load: 20 PSF LIVE / 20 PSF dead (IRC TABLE R802.5.1(2) For ceiling attached to rafters, L/∆ = 240

  • Snow load: Up to 70 PSF, check local conditions for engineering requirements

  • Total floor area: 1,004 SQ FT

  • First floor area:: 808 SQ FT

  • Second floor area: 196 SQ FT > 5’-0”

  • Porch/deck: 207 SQ FT

  • Levels: 2

  • Overal height: 23’ - 6 ⅛”

  • Bedrooms: 2

  • Bathrooms: 1.5

  • Foundation: Ventilated crawl space

  • Heating: Ductless mini-split

  • Water heating: Electric tank

  • Plan is delivered as an immediate printable digital PDF download.

  • Print size: ARCH D 24" X 36” (A1 594 X 841); black & white sheets

    Plan is ready to submit for permitting and Includes electrical plan, window & door schedules, and seismic & high wind braced wall plans

  • A modifiable SketchUp model is available for this plan.

  • CAD line work is available for this plan.
